说明书 Eclear HCE-HU03 加湿器

说明书

2 3 4

6 7 8

5

WARNING

CAUTION

This symbol indicates the "prohibited" matters that must not be implemented.

This symbol indicates the "mandatory" matters that must be implemented.

WARNING

WARNING CAUTION

CAUTION

Do not

disassemble

Name of Each Part

■ Main unit

■ Dedicated USB cable

Preparation

PC

Dedicated USB cable

USB micro B connector

Preparation before use

2

Turning the power on

1

①

②

USB A connector

②

①

①

Remove the cover.

③

②

④

Maximum water level

Cup

Slide

Fixed point

Maximum

water level

Ultrasonic

vibrator

Inner cover

Outer

cover

Air outlet

Protective cover

(Inner cover + Outer cover)

Air inlet

Water tank

Air supply

outlet

Main unit

Slide

USB A connector

Power button

(mode switch button)

USB micro B

connector

Screw the cover counterclockwise,

unscrew the lock and lift the cover up.

Drainage port

Thank you very much for purchasing this product.

This manual includes the operation method and precautions for safe handling of the

product.

Please read this Instruction Manual before use. In addition, please keep this manual

properly after reading.

Make sure there are no missing parts before use. The product is packed with the

greatest care, but if you still find any missing or damaged parts, contact the

distributor from which you purchased the product.

Fixed

point

USB connector slot

Safety Precautions (Be sure to always follow

these precautions)

To prevent personal injury or damage to property of the user and any other

persons, please be sure to observe the precautions outlined below.

■ Hazards and the degree of damage caused by ignoring the precautions and

adopting improper operation method are classified and explained by the

following indications.

This icon indicates "there is a high risk of death or serious injury".

This icon indicates "probability of injury or physical damages can be

anticipated".

Keep this product away from babies and toddlers. In addition, do not play with

this product, otherwise overturning the main unit or improper operation method

may cause an accident.

Do not use this product if it is damaged. If the product is damaged during use,

please cut off the power, unplug the USB cable from the main unit and stop

operation, otherwise it may result in fire or electric shock.

Do not immerse the main unit and USB cable in water or under running water.

In addition, do not use or store this product in a place with high humidity such

as the bathroom or locker room, otherwise it may result in fire, electric shock or

fault.

This product is not a medical inhaler. Do not directly inhale the mist spray

from the air outlet, otherwise it may cause discomfort.

Do not use this product for purposes other than humidifier and aromatherapy

essential oil, weak acid hypochlorite water "ECLEAR ZERO" to avoid accident

and fault.

Do not put foreign objects such as pin and wire in the gap between the air outlet

and the main unit, otherwise it may result in electric shock or injury.

During cleaning and maintenance of the main unit, do not use detergents other

than the kitchen-specific neutral detergent, otherwise the detergent will remain

inside the water tank and produce toxic gases or cause fault.

In addition, the water tank which has completed antibacterial processing may lose

its antibacterial properties.

Do not use or store this product in the following places:

• Places under direct sunlight

• Places near heating devices and other places where the temperature is high

• Humid places, such as the bathroom

• Places with a lot of dust

• Places under frequent vibration

• Place where water in the water tank will freeze

• Unstable places, such as inclined table, etc.

• Place which may block the air inlet, such as on the shaggy carpet, etc.

• Place which may block the air outlet, such as near the curtain

to avoid poor operation, fire or fault.

Do not carelessly touch the main unit and the ultrasonic vibrator or diffuser while

they are in operation and after they have just stopped operation, otherwise it may

cause an accident or injury.

Do not unscrew the cover during operation, otherwise the water, ethereal oil and

weak acid hypochlorite water "ECLEAR ZERO" will be sprayed, which will damage

surrounding objects or cause surrounding objects to enter the main unit, resulting

in some faults.

Do not move the main unit during operation.

If it is necessary to move the main unit, please turn off the power firstly, and then drain

the water in the water tank before any operation. If water is introduced into the main

unit, it may cause a fault.

Do not put any substances other than the instant tap water, ethereal oil and weak

acid hypochlorite water "ECLEAR ZERO" at room temperature in the water tank to

avoid any fault.

In addition, if mineral water and alkaline ionized water, well water and water in water

purifier are used, an odor may be generated.

In case of using aromatherapy essential oil, be sure to adopt the ethereal oil

(essential oil) of 100% natural extracts.

Essential oil containing aroma chemical substances, impurities or solid substances

may cause malfunction.

Do not spill the ethereal oil out of the tank. The water tank and the inner cover are

made of oil-resistant materials, but other parts may be deformed due to some

ingredients contained in the ethereal oil.

If the ethereal oil spills, please wipe it off immediately.

The ethereal oil is easily left inside the tank, so clean the inside of the tank regularly.

Carefully protect this product against tipping over when it is used near electronic

devices such as computer and TV or furniture covered with special painting. In

addition, be sure to use the product in a stable place to avoid tipping over.

Unplug the USB cable from the main unit after use. Failure to unplug the USB

cable may result in an accident when pulling the USB cable.

When you no longer need to use this product, be sure to dispose of it in

accordance with the local regulations.

Connect the USB microB connector of the dedicated USB

cable to the USB connector slot of the main unit.

Connect the USB A connector of the dedicated USB cable to the

USB port of the computer, AC adapter, etc. to supply power.

USB connector slot

• Please use the AC adapter with output power over USB 5V/1A.

• Using a transformer such as travel converter for power supply may

cause overheating or fire.

• Be sure to connect a dedicated USB cable before filling water.

It can also be charged via the USB port of the portable power

source.

(It may not work properly on some computers and portable power

sources, USB hubs, etc.)

Pour about 80 ml of tap water into

the water tank with the cup or other

containers.

The tank has a capacity of approximately

80 ml. Do not exceed the maximum water

level when filling water.

In addition, please do not fill water from

the air outlet without unscrewing the cover,

or directly take the tap water from the tap.

• Disconnect power before adding water.

• When filling water, be sure to unscrew the cover and slowly fill the

water with a cup or other containers.

• It is strictly prohibited to fill water when the product is in operation.

If ethereal oil and weak acid hypochlorite water are

applied, please put the specified amount of ethereal

oil and weak acid hypochlorite water "ECLEAR

ZERO" into the water tank after filling water.

The ethereal oil, weak acid

hypochlorite water "ECLEAR

ZERO" are not included in the

package. During application of

this product, please purchase

the commercially available

ethereal oil (essential oil) of

100% natural extracts and the

weak acid hypochlorite water

"ECLEAR ZERO".

Ethereal

oil

Weak acid hypochlorite

water "ECLEAR ZERO"

8 ml

• Be sure to add water into the tank and then the ethereal oil and

weak acid hypochlorite water "ECLEAR ZERO".

In addition, it is not allowed to directly drip the liquid onto the

ultrasonic vibrator.

• Please reduce the water and the added weak acid hypochlorite

water "ECLEAR ZERO" to avoid exceeding the tank capacity.

Insert the three fixed points

inside the cover into the slide

of the main unit, and turn

clockwise to lock.

Please make sure whether there is a gap between the main unit and

the cover. If yes, the gap may cause water leakage or other faults.

HCE-HU03 Series

Instruction Manual

Household Humidifier

Do not disassemble or modify the main unit.

There is a risk of fire or electric shock.

Failure to do so may result in fire or electric shock due to damage.

Do not apply brute force or impact to the main unit, such as something falling or

knocking on the main unit.

Be sure to drain the water tank after using the product. When draining, be sure to

drain from the drainage port of the main unit. Please be careful to protect the air

supply outlet from water.

This product has completed antibacterial treatment, but when water remains in the

tank, it may cause bacteria or mold reproduction. In addition, if water is introduced

into the air supply outlet, it may cause fault.

Do not connect the power supply when there is no water in the water tank.

Otherwise, the ultrasonic vibrator may be broken, faulty or showing leakage.

CAUTION

CAUTION

CAUTION

Please install the cover onto

the main unit.

ECLEAR MIST

If you made your purchase in another country, please refer to manual from the relevant country.

www.elecom.co.jp/global/download-list/manual/
