说明书 飞利浦 HD4992 炉灶

说明书

Overview

概覽

Preparing for use

準備使用

Using the induction cooker

使用電磁爐

Using the timer

使用定時功能

Cleaning

清潔

Recommended types and sizes of cookware

建議的廚具種類和大小

Specifications are subject to change without notice

© 2016 Koninklijke Philips N.V.

All rights reserved.

HD4992_AUS_UM_v0.5_160517

HD4992

Always there to help you

Register your product and get support at

www.philips.com/welcome

Preset time for delayed cooking

預約時間延時烹飪

English

1 Your induction cooker

Congratulations on your purchase and welcome to

Philips! To fully benet from the support that Philips

oers, register your product at www.philips.com/

welcome.

2 What’s in the box

Induction cooker main unit Warranty card

Important information leaet User manual

Magnet Free carry bag

Overview

a

Cooking plate

d

Control panel

b

Cooking zone

e

Air outlets

c

Air inlet

f

Power cord

Controls overview

g

Display screen

n

Fry/Saute

h

Child Lock

o

Milk/Fondue

i

Soup/Congee

p

Slow Cook

j

Boil

q

On/O

k

Manual

r

Power Slider

l

Steam/Stew

s

Preset/Cooking Time

m

Warm

3 Before first use

Remove all packaging materials from the induction

cooker.

Preparing for use

1 Place the appliance on a dry, stable and level

surface.

2 Make sure there is at least 10cm free space around

the appliance to prevent overheating.

3 Always place the cookware on the cooking zone

during cooking.

4 Make sure you use cookware of the correct types

and sizes (see Fig ).

Recommended types and sizes of

cookware

Material Cookware with a bottom made of iron or

magnetic stainless steel

Shape Cookware with a at bottom

4 Using the induction cooker

There are eight cooking modes: Soup/Congee ( ),

Boil ( ), Manual ( ), Steam/Stew ( ),

Warm ( ), Fry/Saute ( ), Milk/Fondue ( ) and

Slow Cook ( ).

1 Follow the steps in “Preparing for use”.

2 Touch the On/O icon ( ), the On/O indicator

lights up.

3 Touch the cooking icons to choose the desired

cooking mode. The corresponding indicator lights

up and the induction cooker starts working in the

selected mode.

4 When the cooking is nished, touch the On/O

icon ( ) to switch o the appliance.

5 Unplug the induction cooker after the fan stops

working.

Note

•

During cooking, you can change the power level by

moving your ngers up and down on the power slider.

• In Soup/Congee ( ), Boil ( ), Soup ( ), Steam/

Stew (

), and Milk/Fondue ( ) modes, the cooking

power automatically changes for better cooking result.

Default cooking time and temperature

Refer to below table for the default cooking time and

temperature of dierent cooking modes.

Cooking

mode

Cooking

temperature

Default cooking

power

Soup/

Congee ( )

100°C

1000W (0-3 mins)

1600W (3-15 mins)

1000W (15-20 mins)

400W (20-60 mins)

100W (60 mins

onwards)

Boil (

)

100(±20)°C

Starts with 1800W.

When the water

temperature

reaches 80±20°C,

the power drops to

1000W. After the

preset cooking time

or the timer(if set)

has elapsed,the

appliance turns o

automatically.

Manual (

)

100(±20)°C 1800W

Steam/Stew

(

)

100(±20)°C

1800W (0-5 mins)

1400W (5-15 mins)

When water is

brought to boil,

the power drops to

1000W.

100W (15 mins

onwards)

EN User manual ZH-T 使用手冊

Cooking

mode

Cooking

temperature

Default cooking

power

Warm ( )

160(±20)°C 1000W

Fry/Saute

(

)

200(±20)°C 1200W

Milk/Fondue

(

)

60(±20)°C 800W

Slow Cook

(

)

100(±20)°C

1800W (0-3 mins)

1600W (3-15 mins)

1400W (15-25 mins)

400W (25 mins

onwards)

Cooking

mode

Default cooking

time

Timer

Soup/

Congee (

)

3 hrs 1-120 mins

Boil (

) 20 mins 0-1 hr

Manual (

) 1 hr 4 hrs

Steam/Stew

(

)

1 hr 1-120 mins

Warm (

) 2 hrs 1-120 mins

Fry/Saute

(

)

2 hrs 1-120 mins

Milk/Fondue

(

)

20 mins /

Slow Cook

(

)

6hrs 1-600 mins

Note

•

Depending on the cookware being used or the

ingredients in the cookware, the actual cooking

temperature may be dierent.

Using the timer

You can use the Preset/Cooking Time ( ) icon to

decide how much time you want the appliance to

work at dierent cooking modes.

1 Follow the steps in “Preparing for use”.

2 Touch the On/O ( ) icon, the On/O indicator

lights up.

3 Choose the desired cooking mode.

4 Touch the Preset/Cooking Time ( ) icon twice,

the timer indicator lights up.

5 Move your nger on the power slider upwards to

set minute and downwards to set hour.

6 When the time has elapsed, the induction cooker

turns o automatically.

• If the magnet sticks to your pan / cookware, then it will be suitable

for use on your Philips induction cooker. Please use the magnet in

the box for checking.

• 如果磁性貼可以貼住您的平底鍋

/

炊具，則該平底鍋

/

炊具適用于您的飛利

浦電磁爐。請使用包裝盒內的磁性貼進行檢測。

Diameter: >12 cm

直徑：大於

12

釐米

Material: Ferrous/Magnetic

材質：鐵制

/

磁性

www.philips.com/welcome

User manual

HD4911

www.philips.com/welcome

Safety leaflet

HD4911

www.philips.com/welcome

Warranty

HD4911

10cm

10cm

c

a

b

d

e

f

g

h

i

j

k

l

m

n

o

p

s

r

q
