We Make A Difference
TM
CREE XM-L LED
MODEL:S10 Baton
LED FLASHLIGHT
标配清单:
手电*1 ,挂绳*1 ,挂环*1 ,说明 书*1.
中文
产品说明及安装指示:
+
-
操作说明:
保修条款:
1.按 照图示 安 装电池 。
2.关 机状态 下,按 下开关 按 键,在1秒内释 放 ,
手电开 启 ,输出 记 忆的亮 度 ,再次 单 按 开关
键,输 出 关闭;
3.关 机状态 下 ,按住 开 关按键1秒 以 上,手
电开启 月 光模式 ;
4.在 月光模 式 下,按 下 开关按 键 并保持1秒
以上, 输 出进入 低 亮,若 持 续按住 按 键 ,输
出在低 – 中 – 高 – 中 – 低 顺 序依次 循 环,释
放按键 , 输出亮 度 锁定。
5.开 机后, 快速 连 按开关 键 两次, 输 出暴
闪;手 电 不记忆 暴 闪状态 ; 在暴闪 状 态 下,
单按开 关 ,关闭 输 出;常 按 开关按 键 , 输出
转入记 忆 的亮度 。
规格参数表:
1. 30天 保 换 期 :Olight手电 产 品 自 售 出之 日起
30天 内 (以 购买 发 票 或 者 其 它 有 效购 买 单 据
上的 日 期 为 准) , 在 正 常使 用 情 况 下, 出 现
产 品 质 量 问 题 , 客 户 可 选 择 更 换 新 品 及 部
件,或 维 修服务 ;
2. 2年 免 费 保 修 期 :Olight手 电 产 品 自 售 出 之
日 起2年 内(以购 买 发 票 或 者 其 它 有 效 购 买 单
据 上 的 日 期 为 准 ) , 用 户 在 正 常 使 用 情 况
下, 出 现 产 品质 量 问 题 ,则 享 受 免 费维 修 服
务;
3.终 身 有 限 保 修 : 在 超 过2年 免 费 保 修 时 间
外,Olight将提 供 有偿 保 修, 更 换配 件 及运 输
费用由 用 户承担 , 不另收 取 人工费 用 ;
4.电 池 质 保 :Olight为 随产 品 提 供 或 单 独 销 售
的 可 充 电 电 池 提 供1年 ( 以 购 买 发 票 或 者 其
它有效 购 买单据 上 的日期 为 准)质 保 ;
5.用 户 保 修 时 凭Olight《质 量 保 证 卡 》 及 购 买
有效 单 据 与 经销 商 联 系 ,由 经 销 商 对消 费 者
提 供 服 务 , 我 公 司 将 对 经 销 商 提 供 服 务 支
持;
We Make A Difference
TM
Thank you for purchasing the OLIGHT S10
Baton flashlight. Please read this manual
carefully before using this product.
Package Contents:
ENGLISH
Flashlight *1 Lanyard *1 Flying ring *1
User' manual *1
+
-
Product description:
Operational instruction:
1. Please install the battery according to the
diagram.
2. Press the switch then release within one
second , the light turns on and output starts at
memorized brightness level. Press the switch
once again to close the output.
3. Keep pressing the switch more than one
second, the light directly enter into moonlight
from off status.
4. Under moonlight mode, keep pressing the
switch more than one second, output comes into
a low brightness level, if the switch is continually
pressed, the output will change as a loop “low -
middle – high – middle – low”. The brightness will
be frozen until the switch is released.
5. To activate strobe, quickly double click the
switch after the light is on, the strobe will not be
memorized. Click the switch again will turn off the
light. Under strobe mode, keep pressing the
switch will quit strobe and back to memorized
brightness level.
Specifications:
L70.5 x D23.0 mm
42g(Without battery)
CREE XM-L
Orange peel
1,800 cd
85 meters
IPX 8
Dimension
Weight
LED
Battery
Reflector
Output and Runtime
Peak Beam intensity
Beam Distance
Waterproof
Impact resistance
2 meters
CR123A or RCR123
Olight Technology Co., Limited
Address: 2/F East, Building A, B3 Block,
Fuhai Industrial Park, Fuyong, Bao'an
District, Shenzhen , China 518103
Tel: +86-755-81452518/81452608
Fax: +86-755-81452508
E-mail:service@olightworld.com
www.olightworld.com
深圳市欧莱特科技有限公司
地址:深 圳 市宝安 区 福永 镇 福海 工 业区
B3区A栋 二 楼东
电话: 0 755 - 81 4 52 5 18/ 814 5 26 0 8
传真: 0755-81452508
E-mail:service@olightworld.com
www.olightworld.com
TM
Olight warrants its products to be free from defects
in materials and workmanship. Within 30 days of
receipt, any defective lights will be offered repair or
replacement by the retailer where the product was
TM
purchased. Olight will repair or replace, at its option
and without charge, any product or part which is
found to be defective under normal use and service
within 24 months counting from the date of
purchasing with proof of purchase, Such repair or
replacement shall be the purchaser’s sole and
exclusive remedy under this warranty, This warranty
does not cover normal maintenance and service and
does not apply to any products or parts which have
been subject to modification, misuse, negligence,
accident, improper maintenance or repair by anyone
TM
other than Olight .
As to those exceed 24 months of the purchase date,
Olight will still provide with warranty service. Labor
is free but cost of parts will be charged. This warranty
covers parts and labor only as specified above.
Freight and transit costs are the responsibility of the
user/owner, not the factory or dealer.
Warranty:
320lumens/1h30min
70lumens/7h30min
5 lumens/ 108h
0.5lumens/360h
strobe: 320 lumens / 3h
Material
Aluminum body with
anti-scratching
type III Hard Anodization
L70.5 x D23.0 mm
42g(不带电池)
CREE XM-L
橘面杯
1,800 cd
85米
IPX 8
尺寸
重量
LED
电池
反光杯
输出亮 度 及
运行时 间
中心光 强 度
最大射 程
防水
抗冲击
2米
CR123A or RCR123
320流明/1. 5小 时
70流 明/7.5小 时
5 流明/ 108小 时
0.5流明/360小时
暴闪: 320 流 明/ 6小 时
材料
铝合金 , 表面三 级
硬质氧 化
感谢 您 购买Olight LED Flashlight ,在使
用前 请 详细 阅读 本说明 书.本说 明书适
用于S10 Baton.
