KLV-24P422C / KLV-24P412C / KLV-22P422C / KLV-22P402C
4-565-798-01(1)
USB Video format
Extension Container Video Codec Audio Codec
.avi AVI
MPEG1
MPEG2
XviD
MPEG4
H.264
MJPEG
PCM
AC3
MPEG1 Layer1/2
MPEG2 AAC
MPEG4 AAC
MPEG4 HE-AAC
WMA V8
MP3
.wmv
.asf
ASF
WMVV9
Xvid
MPEG4
VC-1
MP3
WMA V8
.mp4
.mov
.3gp
MP4
MPEG4
H.264
H.263
MJPEG
MPEG1 Layer1/2
MP3
MPEG2 AAC
MPEG4 AAC
MPEG HE-AAC
.mkv MKV
WMVV9
MPEG4
H.264
VC-1
PCM
MP3
MPEG1 Layer1/2
MPEG2 AAC
MPEG4 AAC
MPEG4 HE-AAC
AC3
WMA V8
.mpg
.mpeg
.vob
.vro
MPEG1 MPEG1
MPEG1 Layer1/2
MP3
AC3
MPEG2PS
MPEG1
MPEG2
MPEG1 Layer1/2
MP3
AC3
.ts
.m2ts
MPEG2TS
MPEG2
H.264
VC-1
MPEG1 Layer1/2
MP3
MPEG2 AAC
MPEG4 HE-AAC
AC3
MPEG4 AAC
USB Music format
Extension Audio Codec
.mp3 MPEG1 Audio Layer 3
.wma WMA V8
.wav LPCM
USB Photo format
Extension Image Codec
.jpg, .jpe, .jpeg JPEG
DCF2.0 or EXIF2.21 supported.
~
• Playback of the above fi le formats is not guaranteed.
• The USB device supports FAT16, FAT32 and NTFS.
4 Settings
You are able to change the settings of your TV from
“Settings” menu
x To select setting options
Settings
Sound
Screen
Channel Set-up
Parental Lock
Set-up
Eco
To select “Settings” category
/
To modify the setting
~
• To exit the setting mode:
• The options you can adjust vary depending on the
situation. Unavailable options are greyed out or not
displayed.
Picture Mode
Sets a picture mode.
Reset
Resets all the “Picture” settings to
factory settings, except “Picture Mode”
and “Intelligent Picture Plus Set-up”.
Backlight
Adjusts the brightness of the backlight.
Increases or decreases picture
contrast.
Brightness
Brightens or darkens the picture.
Colour
Increases or decreases colour
intensity.
Hue
Increases or decreases the green
tones and red tones.
Sharpness
Sharpens or softens the picture.
Colour
Temperature
Adjusts the whiteness of the picture.
Noise
Reduction
Reduces the picture noise (snowy
picture) in a weak broadcast signal.
MPEG Noise
Reduction
Reduces the picture noise in MPEG-
compressed video.
Cinema Drive
Provides improved picture movement
when playing BD (Blu-ray Disc™), DVD
or VCR images taken on fi lm, reducing
picture blur and graininess.
~
• If the image contains irregular signals or too much noise,
“Cinema Drive” is automatically turned off even if “Auto”
is selected.
Advanced
Settings
Set “Picture” settings in more detail.
Intelligent
Picture Plus
Set-up
Enhances picture quality according to
preferred settings, channel or video
input.
Sound
Sound Mode
Sets a sound mode.
Reset
Resets all the “Sound” settings to
factory settings, except “Sound Mode”,
“Dual Sound”, “Speakers” and “Audio
Out”.
Treble
Adjust the treble level
Bass
Adjust the bass level
Sound
Booster
Produces a fuller sound for more
impact, by emphasising the bass
sounds.
Simulated
Stereo
Adds a surround-like effect to mono
programmes.
Intelligent
Volume
Minimizes the difference in volume
level between all programmes and
adverts.
Balance
Emphasises left or right speaker
balance.
Volume Offset
Adjusts the volume level of the current
input relative to other inputs.
Dual Sound
Sets the sound from speaker for a
stereo or bilingual broadcast.
~
• If the stereo sound is noisy when receiving a NICAM
programme, select “Mono”. The sound becomes
monaural, but the noise is reduced.
• If you select other equipment connected to the TV, set
“Dual Sound” to “Stereo”, “Main” or “Sub”. However,
when the external equipment connected to the HDMI jack
is selected, this is fi xed to “Stereo”.
Speakers
Selects sound output from TV speakers
or external audio equipment.
Audio Out
“Variable” : Volume output from audio
out can be controlled
using the TV’s remote.
“Fixed” : The audio output of the TV
is fi xed.
~
• When the input source is set to “Headphone” in the
“Headphone/Audio Out” under the “AV Set-up” menu,
“Audio Out” is not available in the list.
Screen
Wide Mode
Refer (To change the Wide Mode).
Auto Wide
Automatically changes the wide mode
according to the input signal from
an external equipment. To keep your
setting, select “Off”.
z
• Even if “Auto Wide” is set to “On” or “Off”, you can
always modify the format of the screen by pressing
repeatedly.
4:3 Default
Selects the default screen mode for
use with 4:3 broadcasts.
Auto Display
Area
Selects “On” to automatically adjusts
the display area based upon the
content or “Off” to choose from the
“Display Area” options.
Display Area
Adjusts the picture display area.
Horizontal
Shift
Adjusts the horizontal position of the
picture when “Wide Mode” is set to
“Wide Zoom” or “Zoom”.
Vertical Shift
Adjusts the vertical position of the
picture when “Wide Mode” is set to
“Wide Zoom” or “Zoom”.
PC Settings
Selects screen mode or adjusts the
display position of the picture when the
TV receives an input signal from the
connected HDMI PC or PC*.
* KLV-22P422C and KLV-24P422C only.
PC input signal reference chart for HDMI IN 1, 2
Signals
Horizontal
(Pixel)
Vertical
(Line)
Horizontal
frequency
(kHz)
Vertical
frequency
(Hz)
Standard
VGA 640 480 31.5 60 VGA
SVGA 800 600 37.9 60
VESA
Guidelines
XGA 1024 768 48.4 60
VESA
Guidelines
WXGA 1280 768 47.4 60 VESA
WXGA 1280 768 47.8 60 VESA
WXGA 1360 768 47.7 60 VESA
SXGA* 1280 1024 64 60 VESA
HDTV* 1920 1080 67.5 60 EIA
* KLV-22P402C and KLV-22P422C only
~
• This TV’s PC input does not support Sync on Green/
Composite Sync and interlaced signal.
• This TV’s PC input supports signals in the above chart with
a 60 Hz vertical frequency.
Channel Set-up
1 Digit Direct
When “1 Digit Direct” is set to “On”,
select a channel using one preset
number button (0 - 9) on the remote.
~
• When “1 Digit Direct” is set to “On”, you cannot select
channel numbers 10 and above entering next digit using
the remote.
Auto Tuning
Tunes in all the available channels.
Programme
Sorting
Changes the order in which the
channels are stored on the TV.
Programme
Labels
Assigns a channel name of your choice
up to seven letters or numbers.
Manual
Programme
Preset
Sets programme channels manually.
~
• In “Audio Filter”, you cannot receive stereo or dual sound
when “High” is selected.
FM Radio
Set-up
Preset up to 30 FM radio stations that
can be received in your area.
Parental Lock
PIN Code
Sets up TV to block channel or external
input. Use 0-9 on the remote to enter a
four-digit PIN code.
Change PIN
Code
Selects to change your PIN code.
Programme
Block
Blocks an individual channel from
being watched. To view a blocked
channel, select “Unblocked”.
External Input
Lock
Locks an external input from being
watched. To view a blocked external
input, select “Unblocked”.
~
• Entering the correct PIN code for blocked channel or
external input will temporarily deactivates the “Parental
Lock” feature. To reactivate the “Parental Lock” settings,
turn off and on the TV.
z
• If you lost your PIN code, refer to (Troubleshooting).
Set-up
Photo Frame
Settings*
Sets desired displays, image or music
selection during “Photo Frame Mode”.
* KLV-22P422C and KLV-24P422C only
USB Auto
Start
Automatically enters the thumbnail view
of the last played Photo/Music/Video
when the TV is turned on and a USB
device is connected to the USB port
then turned on.
Clock/Timers
Sets the timer to turn on/off the TV
using “On Timer”, and “Clock Set”.
Auto Start-up
Starts the initial set-up procedure.
Language
Selects the language in which the
menus are displayed.
Start-up
Logo
Select “On” to display logo when the
TV is turned on. Select “Off” to disable
it.
AV Set-up
Selects settings for connected
equipment or input source.
~
• When the input source is set to “Skip” in the “Video
Labels” under the “AV Set-up” menu, that input is
greyed out in the list.
HDMI Setup
Allows the TV to communicate with
equipment that is compatible with the
CEC Control function, and connected
to the HDMI jacks of the TV. Note that
communication settings must also be
made on the connected equipment.
Product
Information
Displays your TV’s product information.
Factory
Settings
Resets all settings to factory settings.
After completing this process, the initial
set-up screen is displayed.
Eco
Reset
Resets the current Eco settings to the
default values.
Power Saving
Reduces power consumption of the TV
by adjusting the backlight.
Idle TV
Standby
Turns the TV off after it has been kept
idle for the preset length of time.
PC Power
Management*
Switches the TV to standby mode when
the TV receives no signal from the PC
input source for 30 seconds.
* KLV-22P422C and KLV-24P422C only
Specifi cations
System
Panel system
LCD (Liquid Crystal Display) Panel
TV system
B/G, I, D/K, M
Colour/video system
PAL, PAL60, SECAM, NTSC4.43, NTSC3.58
Channel Coverage
Analogue: UHF/VHF/Cable, depending on your
country/area selection.
Sound Output
10 W + 10 W
Input/Output jacks
Antenna (aerial)/cable
75 ohm external terminal for VHF/UHF
COMPONENT IN/
AUDIO
YP
B
P
R
(Component Video): 1080p (50, 60Hz), 1080i
(50, 60Hz), 720p (50, 60Hz), 576p, 576i, 480p, 480i
Audio input (phono jacks)
VIDEO IN
Video input (common phono pin with Y input)
HDMI IN 1, 2
(HDMI IN 2 for KLV-24P412C & KLV-24P422C only)
Video: 1080p (24, 30, 50, 60Hz), 1080i (50, 60Hz),
720p (24, 30, 50, 60Hz), 576p, 576i, 480p, 480i,
PC Formats
Audio: Two channel linear PCM: 32, 44.1 and 48kHz,
16, 20 and 24 bits, Dolby Digital
MHL (common with HDMI IN for KLV-22P422C only,
HDMI IN 2 for KLV-24P422C only)
Video: 1080p (24, 30Hz), 1080i (50, 60Hz), 720p
(24, 30, 50, 60Hz), 576p, 576i, 480p, 480i
Audio: Two channel linear PCM: 32, 44.1 and 48kHz,
16, 20 and 24 bits, Dolby Digital
PC IN *
PC Input (D-sub 15-pin)
G: 0.7 Vp-p, 75 ohms/R: 0.7 Vp-p,
75 ohms/HD: 1-5 Vp-p/VD: 1-5 Vp-p
* KLV-22P422C and KLV-24P422C only
PC / HDMI AUDIO IN *
PC audio input (mini jack)
* KLV-22P422C and KLV-24P422C only
AUDIO OUT/i
Audio output (stereo minijack)
Headphones jack
USB port
Others
Operating temperature
0 °C - 40 °C
Operating humidity
10 % - 80 % RH (non-condensing)
Power and others
Power requirements
AC IN 110 V – 240 V AC, 50/60 Hz
Screen size (measured diagonally) (Approx.)
KLV-24P422C: 59.9 cm / 24 inches
KLV-24P412C: 59.9 cm / 24 inches
KLV-22P422C: 54.6 cm / 22 inches
KLV-22P402C: 54.6 cm / 22 inches
Display resolution
KLV-24P422C: 1,366 dots (horizontal) x 768 lines
(vertical)
KLV-24P412C: 1,366 dots (horizontal) x 768 lines
(vertical)
KLV-22P422C: 1,920 dots (horizontal) x 1,080 lines
(vertical)
KLV-22P402C: 1,920 dots (horizontal) x 1,080 lines
(vertical)
Power consumption
KLV-24P422C: 48 W
KLV-24P412C: 41 W
KLV-22P422C: 44 W
KLV-22P402C: 38 W
Dimensions (Approx.) (w × h × d)
with Table–Top Stand
KLV-24P422C: 558 x 367 x 147 mm
KLV-24P412C: 558 x 367 x 147 mm
KLV-22P422C: 509 x 340 x 147 mm
KLV-22P402C: 509 x 340 x 147 mm
without Table–Top Stand
KLV-24P422C: 558 x 341 x 65 mm
KLV-24P412C: 558 x 341 x 65 mm
KLV-22P422C: 509 x 314 x 65 mm
KLV-22P402C: 509 x 314 x 65 mm
Mass (Approx.)
with Table–Top Stand
KLV-24P422C: 4.2 kg
KLV-24P412C: 4.2 kg
KLV-22P422C: 3.8 kg
KLV-22P402C: 3.8 kg
without Table–Top Stand
KLV-24P422C: 4.0 kg
KLV-24P412C: 4.0 kg
KLV-22P422C: 3.6 kg
KLV-22P402C: 3.6 kg
~
• Design and specifi cations are subject to change without
notice.
Troubleshooting
No picture and no sound
• Check the antenna/cable connection.
• Connect the TV to the AC power outlet (mains socket),
and press "/1 on the TV. If TV is in standby mode (the "/1
(standby) indicator on the TV front panel is off), press "/1.
No picture from the connected equipment
• Turn the connected equipment on.
• Check the connection between the optional equipment
and the TV.
• Press
repeatedly to select the desired input.
• Correctly insert the USB / MHL device.
• For USB device: Make sure that the USB device has been
properly formatted.
• For MHL device: Ensure that the MHL device is connected
to the HDMI IN / MHL jack (KLV-22P422C only) and HDMI
IN 2 / MHL jack (KLV-24P422C only) using an MHL cable.
• Operations are not guaranteed for all USB / MHL devices.
Also, operations differ depending on the features of the
USB / MHL device.
Double images or ghosting
• Check the antenna/cable connection, location or direction.
Only snow and noise appear on the screen
• Check if the antenna is broken or bent.
• Check if the antenna has reached the end of its
serviceable life (three to fi ve years in normal use, one to
two years at the seaside).
Distorted picture (dotted lines or stripes)
• Keep the TV away from electrical noise sources such as
cars, motorcycles, hair-dryers or optional equipment.
• When installing optional equipment, leave some space
between the optional equipment and the TV.
• Check the antenna/cable connection.
• Keep the antenna/cable away from other connecting
cables.
Picture or sound noise when viewing a TV channel
• Adjust “AFT” (Automatic Fine Tuning) under the “Manual
Programme Preset” menu to obtain better picture
reception.
Tiny black points and/or bright points appear on the
screen
• The screen is composed of pixels. This is not a
malfunction.
Picture contours are distorted
• Change the current setting of “Cinema Drive” to other
settings.
No colour on programmes
• Select “Reset”.
Sound
No sound, but good picture
• Press 2 +/– or % (Mute).
• Check if the “Speakers” is set to “TV Speakers”.
No sound or noisy sound
• Check if the TV system setting under the “Manual
Programme Preset” menu is appropriate.
Channels
Some channels are blank
• The channel is for scrambled/subscription service only.
Subscribe to a pay TV service.
• Channel is used only for data (no picture or sound).
• Contact the broadcaster for transmission details.
General
The TV turns off automatically (the TV enters
standby mode)
• Check if the “Idle TV Standby” is activated.
• Check if the “Sleep Timer” under the “Clock/Timers”
menu is activated.
Some input sources cannot be selected
• Press and select “Settings” t “Set-up” t “AV
Set-up” t “Video Labels” and cancel “Skip” of the input
source.
The remote does not function
• Replace the batteries.
HDMI equipment does not appear on “HDMI Device
List”
• Check that your equipment is compatible with the CEC
Control function.
The “Parental Lock” password has been forgotten
• Press and select “Settings” t ”Parental Lock”
t ”PIN code” then enter 9999 for the PIN code (PIN
code 9999 is always accepted.).
TV does not output picture and/or sound from the
MHL device
• Disconnect the MHL cable, then reconnect it, or power
the MHL device off then on again and release its lock.
It took long time to open USB drive folders/fi les
• Depending on the quantity/size of folders/fi les, it may
take longer time to open.
Safety information
WARNING
Batteries must not be exposed to excessive heat such as sunshine,
fi re or the like.
Installation/Set-up
Install and use the TV set in accordance with the instructions below
in order to avoid any risk of fi re, electrical shock or damage and/or
injuries.
Installation
• The TV set should be installed near an easily accessible AC power
outlet (mains socket).
• Place the TV set on a stable, level surface to avoid it from falling
down and cause personal injury or damage to the TV.
• Only qualifi ed service personnel should carry out wall installations.
• Be sure to use the screws supplied with the Wall-Mount Bracket
when attaching the mounting hooks to the TV set. The supplied
screws are designed as indicated by illustration when measured
from the attaching surface of the mounting hook. The diameter and
length of the screws differ depending on the Wall-Mount Bracket
model.
Use of screws other than those supplied may result in internal
damage to the TV set or cause it to fall, etc.
22"/24" TV: 6.5 mm ~ 11 mm
Screw (supplied with the
Wall-Mount Bracket)
Mounting Hook
Hook attachment on rear
of TV set
Transporting
• Before transporting the TV set, disconnect all cables.
• Two or more people are needed to transport a large TV set.
• When transporting the TV set by hand, hold it as
shown in the illustration. Do not put stress on the
LCD panel and the frame around the screen.
• When transporting the TV set, do not subject it to
jolts or excessive vibration.
• When transporting the TV set for repairs or when
moving, pack it using the original carton and packing material.
Ventilation
• Never cover the ventilation holes or insert anything in the cabinet.
• Leave space around the TV set as shown below.
• Make sure that your TV has adequate ventilation. Allow enough
space around the TV as shown in the illustration.
Installed on the wall
30 cm
10 cm
10 cm
10 cm
Leave at least this space around
the set.
Installed with stand
30 cm
10 cm
10 cm 6 cm
Leave at least this space around
the set.
• To ensure proper ventilation and prevent the collection of dirt or dust:
− Do not lay the TV set fl at, install upside down, backwards, or
sideways.
− Do not place the TV set on a shelf, rug, bed or in a closet.
− Do not cover the TV set with a cloth, such as curtains, or items
such as newspapers, etc.
− Do not install the TV set as shown below.
Air circulation is blocked.
WallWall
AC power cord (mains lead)
Handle the AC power cord (mains lead) and outlet (mains socket) as
follows in order to avoid any risk of fi re, electrical shock or damage
and/or injuries:
− The shape of AC power plug (mains plug), which is supplied with
the TV set, varies depending on the regions. Be sure to connect the
appropriate supplied AC power cord (mains lead) with the plug that
fi ts into the AC power outlet (mains socket).
− Use only Sony supplied AC power cords (mains lead), not those of
other brands.
− Insert the plug fully into the AC power outlet (mains socket).
− Operate the TV set on a 110–240 V AC supply only.
− When wiring cables, be sure to unplug the AC power cord (mains
lead) for your safety and take care not to catch your feet on the
cables.
− Disconnect the AC power cord (mains lead) from the AC power
outlet (mains socket) before working on or moving the TV set.
− Keep the AC power cord (mains lead) away from heat sources.
− Unplug the AC power plug (mains plug) and clean it regularly. If the
plug is covered with dust and it picks up moisture, its insulation may
deteriorate, which could result in a fi re.
Notes
• Do not use the supplied AC power cord (mains lead) on any other
equipment.
• Do not pinch, bend, or twist the AC power cord (mains lead)
excessively. The core conductors may be exposed or broken.
• Do not modify the AC power cord (mains lead).
• Do not put anything heavy on the AC power cord (mains lead).
• Do not pull on the AC power cord (mains lead) itself when
disconnecting the AC power cord (mains lead).
• Do not connect too many appliances to the same AC power outlet
(mains socket).
• Do not use a poor fi tting AC power outlet (mains socket).
Prohibited Usage
Do not install/use the TV set in locations, environments or situations
such as those listed below, or the TV set may malfunction and cause a
fi re, electrical shock, damage and/or injuries.
Location:
• Outdoors (in direct sunlight), at the seashore, on a ship or other
vessel, inside a vehicle, in medical institutions, unstable locations,
near water, rain, moisture or smoke.
• If the TV is placed in the changing room of a public
bath or hot spring, the TV may be damaged by
airborne sulfur, etc.
• For best picture quality, do not expose the screen to
direct illumination or sunlight.
• Avoid moving the TV from a cold area to a warm area. Sudden room
temperature changes may cause moisture condensation. This may
cause the TV to show poor picture and/or poor colour. Should this
occur, allow moisture to evaporate completely before powering the
TV on.
• Never spray water or detergent directly on the
TV set. It may drip to the bottom of the screen or
exterior parts and enter the TV set, and may cause
damage to the TV set.
Environment:
• Places that are hot, humid, or excessively dusty; where insects may
enter; where it might be exposed to mechanical vibration, near
fl ammable objects (candles, etc). The TV set shall not be exposed to
dripping or splashing and no objects fi lled with liquids, such as
vases, shall be placed on the TV.
• Do not place the TV in a humid or dusty space, or
in a room with oily smoke or steam (near cooking
tables or humidifi ers). Fire, electric shock, or
warping may result.
• Do not install the TV in places subject to extreme
temperature such as in direct sunlight, near a radiator or a heating
vent. The TV may overheat in such condition which can cause
deformation of the enclosure and/or TV malfunction.
Situation:
• Do not use when your hands are wet, with the cabinet removed, or
with attachments not recommended by the manufacturer. Disconnect
the TV set from AC power outlet (mains socket) and antenna during
lightning storms.
• Do not install the TV so that it sticks out into an
open space. Injury or damage from a person or
object bumping into the TV may result.
Broken pieces:
• Do not throw anything at the TV set. The screen
glass may break by the impact and cause serious injury.
• If the surface of the TV set cracks, do not touch it until you have
unplugged the AC power cord (mains lead). Otherwise electric
shock may result.
When not in use
• If you will not be using the TV set for several days, the TV set should
be disconnected from the AC power (mains) for environmental and
safety reasons.
• As the TV set is not disconnected from the AC power (mains) when
the TV set is just turned off, pull the plug from the AC power outlet
(mains socket) to disconnect the TV set completely.
• However, some TV sets may have features that require the TV set to
be left in standby to work correctly.
For children
• Do not allow children to climb on the TV set.
• Keep small accessories out of the reach of children, so that they are
not mistakenly swallowed.
If the following problems occur...
Turn off the TV set and unplug the AC power cord (mains lead)
immediately if any of the following problems occur.
Ask your dealer or Sony service centre to have it checked by qualifi ed
service personnel.
When:
− AC power cord (mains lead) is damaged.
− Poor fi tting of AC power outlet (mains socket).
− TV set is damaged by being dropped, hit or having something
thrown at it.
− Any liquid or solid object falls through openings in the cabinet.
About LCD Monitor Temperature
When the LCD Monitor is used for an extended period, the panel
surrounds become warm. You may feel hot when touching there by
the hand.
WALL-MOUNT BRACKET
Below information shows the correct handling of the Wall-Mount
Bracket. Be sure to read this information thoroughly and use the Wall-
Mount Bracket correctly.
To Customers:
Be sure to observe the following precautions for safety to prevent a
serious injury through fi re, electric shock, the product toppling over, or
the product dropping.
• Be sure to subcontract the installation to licensed contractors and
keep small children away during installation.
• Be sure to subcontract moving or dismounting of the TV to licensed
contractors.
• Do not remove screws, etc., after mounting the TV.
• Do not make alterations to the parts of the Wall-Mount Bracket.
• Do not mount any equipment other than the specifi ed product.
• Do not apply any load other than the TV on the Wall-Mount Bracket.
• Do not lean on or hang from the TV.
• Do not handle the TV with excessive force during cleaning or
maintenance.
To Sony Dealers and Contractors:
The following instructions are for Sony dealers and contractors only. Be
sure to read safety precautions described below and pay special
attention to safety during the installation, maintenance and checking of
this product.
• Do not install the Wall-Mount Bracket on wall
surfaces where the corners or the sides of the TV
are protruding away from the wall surface.
• Do not install the TV over or under an
air-conditioner.
• Be sure to install the Wall-Mount Bracket
securely to the wall. If any of the screws are loose
or fall out, the Wall-Mount Bracket may fall and cause
injury or property damage.
• Be sure to use the supplied screws and attachment
parts properly following the instructions given in this
instruction manual. If you use substitute items, the
TV may fall and cause bodily injury to someone or
damage to the TV.
• Be sure to tighten the screws securely in the
designated position.
• Be careful not to subject the TV to shock during installation.
• Be sure to install the TV on a wall that is both perpendicular and fl at.
• After proper installation of the TV, secure the cables properly.
• Do not allow the AC power cord (mains lead)
or the connecting cable to be pinched as the
internal conductors may become exposed and
cause a short circuit or an electrical break.
Precautions
Viewing the TV
• View the TV in moderate light, as viewing the TV in poor light or during
long period of time, strains your eyes.
• When using headphones, adjust the volume so as to avoid excessive
levels, as hearing damage may result.
LCD Screen
• Although the LCD screen is made with high-precision technology and
99.99% or more of the pixels are effective, black dots may appear or
bright points of light (red, blue, or green) may appear constantly on
the LCD screen. This is a structural property of the LCD screen and is
not a malfunction.
• Do not push or scratch the front fi lter, or place objects on top of this TV
set. The image may be uneven or the LCD screen may be damaged.
• If this TV set is used in a cold place, a smear may occur in the picture
or the picture may become dark. This does not indicate a failure.
These phenomena disappear as the temperature rises.
• Ghosting may occur when still pictures are displayed continuously. It
may disappear after a few moments.
• The screen and cabinet get warm when this TV set is in use. This is
not a malfunction.
• The LCD screen contains a small amount of liquid crystal. Follow your
local ordinances and regulations for disposal.
Handling and cleaning the screen surface/
cabinet of the TV set
Be sure to unplug the AC power cord (mains lead) connected to the TV
set from AC power outlet (mains socket) before cleaning.
• To remove dust from the screen surface/cabinet, wipe gently with a
soft cloth. If dust is persistent, wipe with a soft cloth slightly moistened
with a diluted mild detergent solution.
• Never spray water or detergent directly on the TV
set. It may drip to the bottom of the screen or exterior
parts and enter the TV set, and may cause damage
to the TV set.
• Never use any type of abrasive pad, alkaline/
acid cleaner, scouring powder, or volatile solvent, such as alcohol,
benzene, thinner or insecticide. Using such materials or maintaining
prolonged contact with rubber or vinyl materials may result in damage
to the screen surface and cabinet material.
• Periodic vacuuming of the ventilation openings is recommended to
ensure to proper ventilation.
• When adjusting the angle of the TV set, move it slowly so as to prevent
the TV set from moving or slipping off from its table stand.
Optional Equipment
Keep optional components or any equipment emitting electromagnetic
radiation away from the TV set. Otherwise picture distortion and/or noisy
sound may occur.
Caution about handling the remote control
• Observe the correct polarity when inserting batteries.
• Do not use different types of batteries together or mix old and new
batteries.
• Dispose of batteries in an environmentally friendly way. Certain regions
may regulate the disposal of batteries. Please consult your local
authority.
• Handle the remote with care. Do not drop or step on it, or spill liquid
of any kind onto it.
• Do not place the remote in a location near a heat source, a place
subject to direct sunlight, or a damp room.
WALL-MOUNT BRACKET
• If you use the TV installed on the Wall-Mount Bracket for a long time,
the wall behind or above the TV may become discoloured or the
wallpaper may come unstuck, depending on the material of the wall.
• If the Wall-Mount Bracket is removed after installing it on the wall, the
screw holes are left.
• Do not use the Wall-Mount Bracket in a place where it is subjected to
mechanical vibrations.
Loading…
常见问题
请给产品评分，告知您对索尼 Bravia KLV-22P422C 液晶电视看法。您是否希望分享对该产品的体验或提出问题？请在页面底部留言。有关本说明书的更多信息
我们知道，为您的 索尼 Bravia KLV-22P422C 液晶电视 提供纸质手册是件好事。 您随时可以从我们的网站下载该手册并自行打印。 如果您想要原始手册，我们建议您联系Sony。 他们也许能够提供原始手册。 您是否正在寻找其他语言版本的 索尼 Bravia KLV-22P422C 液晶电视 手册？ 在我们的主页上选择您的首选语言并搜索型号以查看我们是否有可用。
规格
| 品牌 | Sony |
| 模型 | Bravia KLV-22P422C |
| 类别 | 液晶电视 |
| 文件类型 | |
| 文件大小 | 1.07 MB |
关于 索尼 Bravia KLV-22P422C 液晶电视 的常见问题
我们的支持团队将搜索有用的产品信息并回答常见问题。如果您在常见问题中发现不准确的回答，请使用联系表格告知我们。
如何测量LCD电视的英寸? 验证
通过测量屏幕左上角和右下角（非电视边缘）之间的对角线距离即可测出LCD电视的英寸。1英寸等于2.54厘米，所以当测量值为99厘米时，LCD电视为39英寸。
有帮助 (543) 阅读更多我的遥控器也可以在相同品牌的其他电视型号上使用吗？ 验证
通常，电视遥控器也可以在相同品牌的相似型号上使用。但是，它可以在该品牌的所有型号上使用都是不寻常的。通用遥控器更适合执行此操作。
有帮助 (340) 阅读更多LCD和LED的区别是什么？ 验证
这两种技术都使用一个自身不发光的LCD屏幕。不同之处在于屏幕后面的光线。对于液晶显示屏，这是由冷阴极荧光灯(CCFL)和LED使用的LED灯。
有帮助 (303) 阅读更多我可以自己修理坏了的像素吗？ 验证
坏点和残留像素之间存在差异。被卡住的像素仍然是彩色的，可以通过在像素上施加轻微的压力来固定它，直到它恢复自身为止。坏点始终为黑色或白色，无法自行修复。
有帮助 (300) 阅读更多为什么遥控器上的数字旁边有字母？ 验证
某些电视设置可能要求您输入字母。一个按钮上通常有三个字母或其他字符。当需要输入字母时，您可以按一次该按钮输入第一个字母，按两次输入第二个字母，然后按3次输入第三个字母。这样，可以用最少数量的按钮来编写文本。
有帮助 (246) 阅读更多如何正确清洁液晶电视？ 验证
关闭电视，然后用超细纤维布擦拭屏幕上的灰尘。请勿使用纸张，这可能会导致刮擦。请勿施加太大压力，否则可能会损坏像素。使用专用洗涤剂或将1份醋与1份水混合制成洗涤剂。用清洁剂润湿抹布并清洁屏幕。确保布不是太湿。通过旋转运动去除污渍。用第二块超细纤维布擦干屏幕，以防止条纹。
有帮助 (209) 阅读更多我看电视的最佳距离是多少? 验证
这部分取决于个人偏好，但根据经验，最佳的观看距离大约是电视机对角线屏幕大小的三倍。对于一台60英寸(152厘米)的电视机，最佳的观看距离是180英寸或4.5米左右。
有帮助 (206) 阅读更多
加入有关该产品的对话
您可以在这里分享您对 索尼 Bravia KLV-22P422C 液晶电视 的看法。 如果您有疑问，请先仔细阅读手册。 可以使用我们的联系表索取手册。
